1J46 High Permeability Soft Magnetic Alloy
1J46 High Permeability Soft Magnetic Alloy is a soft magnetic alloy with a medium nickel content, ranging from 45.0% to 46.5%. Nickel is the main element in this alloy. The nickel content of approximately 45% results in a face-centered cubic (FCC) austenitic structure at room temperature, providing the structural basis for high magnetic permeability and higher saturation magnetic induction. Its resistivity is 0.45 μΩ·m, which is a medium value among nickel-iron alloys, helping to suppress eddy currents in alternating magnetic fields; its density is 8.2 g/cm³, a key parameter for calculating the mass of electromagnetic components, consistent with its nickel content; and its saturation magnetostriction coefficient is 25 × 10⁻⁶, ensuring stability during the magnetization process.
- Specification
- Contact Us
Gradeand Main Chemical Composition(%)
| Grade | C | P | S | Mn | Si | Ni | Cr | Co | Mo | Cu (Max) | Fe |
| 1J46 | ≤0.03 | ≤0.02 | ≤0.02 | 0.6–1.1 | 0.15–0.30 | 45.0–46.5 | — | — | — | ≤0.2 | Bal |
| 1J50 | ≤0.03 | ≤0.02 | ≤0.02 | 0.3–0.6 | 0.15–0.30 | 49.0–50.0 | — | — | — | ≤0.2 | Bal |
| 1J79 | ≤0.03 | ≤0.02 | ≤0.02 | 0.6–1.1 | 0.30–0.50 | 78.5–81.5 | — | — | 3.8–4.1 | ≤0.2 | Bal |
| 1J85 | ≤0.03 | ≤0.02 | ≤0.02 | 0.3–0.6 | 0.15–0.30 | 79.0–81.0 | — | — | 4.8–5.2 | ≤0.2 | Bal |
Mechanical Property
| Grade | Resistivity (μΩ·m) | Density (g/cm³) | Resistivity (μΩ·m) | Saturated magnetic extension coefficient (×10⁻⁶) | Brinell Hardness (HBs) | Tensile strength (MPa) | Yield Strength (MPa) | Elongation (%) | ||||
| Cold-hardened | Annealed | Cold-hardened | Annealed | Cold-hardened | Annealed | Cold-hardened | Annealed | |||||
| 1J46 | 0.45 | 8.2 | 400 | 25 | 170 | 130 | 735 | - | 735 | - | 3 | - |
| 1J50 | 0.45 | 8.2 | 500 | 25 | 170 | 130 | 785 | 450 | 685 | 150 | 3 | 37 |
| 1J79 | 0.55 | 8.6 | 450 | 2 | 210 | 120 | 1030 | 560 | 980 | 150 | 3 | 50 |
| 1J85 | 0.56 | 8.75 | 400 | 0.5 | - | - | - | - | - | - | - | - |
